Description Specifications & Technical Details HARDWARE FEATURES Interface 4 10/100Mbps LAN Ports 1 10/100Mbps WAN Port USB 2.0 Port Button WPS/Reset Button Wireless On/Off Button Power On/Off Button External Power Supply 12VDC / 1.5A Dimensions ( W x D x H ) 7.2 x 4.9 x 1.3 in. (182.95 x 123.5 x 32.1 mm) Antenna Type 2 Dual Band External Antennas WIRELESS FEATURES Wireless Standards IEEE 802.11n/g/b 2.4GHz IEEE 802.11ac/n/a 5GHz Frequency 2.4GHz and 5GHz Signal Rate 2.4GHz: Up to 300Mbps 5GHz: Up to 867Mbps Reception Sensitivity 5GHz: 11a 54M: -76dBm 11ac VHT20 MCS8: -70dBm 11ac VHT40 MCS9: -65.5dBm 11ac VHT80 MCS9: -61.5dBm 2.4GHz: 11g 54M: -76dBm 11n HT20 MCS7: -74dBm 11n HT40 MCS7: -71d Transmit Power CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption SOFTWARE FEATURES Quality of Service WMM, Bandwidth Control WAN Type Dynamic IP/Static IP/PPPoE/ BigPond/ /L2TP(Dual Access) /PPTP(Dual Access) Management Access Control Local Management Remote Management DHCP Server, Client, DHCP Client List, Address Reservation Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS DynDns, Comexe, NO-IP VPN Pass-Through PPTP, L2TP, IPSec Access Control Parental Control, Local Management Control, Host List, Access Schedule, Rule Management Firewall Security DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding Protocols Supports IPv4 and IPv6 USB Sharing Support Samba(Storage)/FTP Server/Media Server/Printer Server Guest Network 2.4GHz guest network × 1 5GHz guest network × 1 OTHERS Certification CE, FCC, RoHS Package Contents AC1200 Wireless Dual Band Router Archer C50 Power supply unit Resource CD Ethernet Cable Quick Installation Guide System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8/8.1/10 MAC OS, NetWare, UNIX or Linux Environment Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
